Chamber working temperature: Often 121 °C to 139 °C depending on design and load. Working pressure: Typical ~0.22-0.25 MPa (~2.2-2.5 bar) for sterilization of large loads.

Construction: Inner chamber, jacket and outer wall built of SS 304/SS 316 stainless steel, with welded construction and double/triple wall insulation.

Capacity/Dimensions: Examples include 182-1215 L volumes; rectangular/internal sizes e.g., 450×450×900 mm up to 900 liters+.

Power/Steam supply: Requires robust power or steam supply; e.g., for 1500 L model, inner dimension 1500×680×1180 mm, outer dimension 1790×1450×1950 mm.

Door/Loading: Horizontal door(s) – sliding or hinged, sometimes double doors (sterile to non-sterile side) for clean room transfer.

Control & Safety: Microprocessor/PLC controls, automatic purging of air, door interlock when pressure present, safety valves, digital displays of parameters.

Insulation & Jacket: Double/triple walled, heavy gauge SS, glass-wool or similar insulation between walls to ensure heat retention.

Sterilization cycle time: Similar to vertical but often for larger loads; typical sterilization times quoted ~25-30 minutes at 121 °C for standard loads.

Applications & Compliance: Suitable for large instrument sets, gowns, pharma components, large loads in hospitals and manufacturing; built for GMP/cleanroom compliance.
